RS485 SERIAL CONVERTER
PDF Datasheet
PDF User guide

FEATURES
- Signal protection and electrical isolation for data connections and devices
- Certified to IEEE 1613 and Class 1 Div2
- Operates at –40°C to 85°C
- Extended distances of 5km over Multi-mode fibre and 30km over Single-mode fibre
- Diagnostic LEDs for easier debug of installation
- Built-in mounting brackets and optional mounting shelf
- Packaged in rugged, industrial quality Galva Neal and powder coated shells
- Conformal coated PC Boards
- Powered from Station Battery Bus
- Compatible with all earlier 5845/ 5846 versions of Dymec Link/Repeaters

Dymec model 5845 and 5846 Serial Fibre Links are link/repeaters for EIA 422 and 485 data connections. The 5845/5846 Links provide reliable serial data connectivity over fibre optic facilities in harsh environments where immunity and signal isolation are critical. Optical connectivity provides flexibility, extended distance, operational safety, reduced equipment outages due to electrical surges, and improved signal quality and network performance. 5845/5846 Links support signal rates from DC to 2 Mbps and operate either full- or half-duplex over single- or multi-mode fibre.

Links are easily field configurable for point-to-point, master/slave, loop, bus or star topologies. The 5845/5846 also interoperate with 5843/5844 RS232 Links, the Dymec Network Integration System and Optical Star products to cost effectively create highly scalable data networks with minimum electrical signal exposure.

GarrettCom Links are substation-hardened to IEEE 1613 specifications. They operate in an extended temperature range and optionally take DC power directly from station battery. Flexible mounting options, diagnostic LEDs and integrated optical and electrical signal test features make turning up Link networks simple.
